Adastra Z5M Zoning Mixer 953.019UK

2 input, 5 zone mixer with individual volumes for both inputs and a mono switch for each zone. All inputs and outputs are stereo via balanced XLR connectors. Acts as the central mix and control in an installation serving up to 5 separate stereo speaker zones.

• 2 inputs to 5 zones
• Mono selectable for each zone
• Fully balanced XLR connections

Specifications

• Power supply……………….115/230Vac 50/60Hz (IEC)
• Inputs………………………….Line 1 L+R, Line 2 L+R, balanced XLRF
• Outputs……………………….Zone 1 to 5 L+R, balanced XLRM
• Input impedance…………40k Ohms
• Output impedance………220 Ohms
• Frequency response……20Hz – 25kHz, +0/-1dB
• Signal to noise ratio…….>100dB
• THD……………………………<0.005%
• Dimensions………………….483 x 175 x 44mm
• Weight…………………………2.2kg
