AJAX SURVEILLANCE NVR 16ch HDMI 80Mbps 1080p HAC

• Guiding video to top-tier security
• Efficient video monitoring for any site
• Video monitoring — exactly how it's meant to be
• Complete awareness with a customizable video wall
• Smooth archive navigation
• Rapid and encrypted data transfer
• Easy integration through ONVIF and RTSP
• Instant event-to-video alarm verification
• Built-in motion detection
• Verified evidence with no effort
• Discover future-proof hardware
• HDMI output / two USB ports / AC/DC power connectors
• LED indicator
• Quiet fan for active cooling
• Hard drive latch
• Rule your video surveillance
• Hassle-free installation and setup
• Established security experience



Specifications

Video

• Video input : 16 channels
• Recording resolution : 8MP / 6MP / 5MP / 4MP / 3MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF
• HDMI output resolution : 1920 × 1080 / 1600 × 1200 / 1280 × 1024 / 1280 × 720 px
• Live view / playback resolution : 8MP / 6MP / 5MP / 4MP / 3MP / 1080p / 720p / D1 / VGA / CIF

Decoding

• Format : H.265 / H.264 / JetSparrow
• Capability : 1 × channel at 8MP , 3 × channel at 5MP / 4 × channel at 4MP / 4 × channel at 1080p / 10 × channel at 720p / 16 × channel at 1024 × 576 px
• Live view window division : templates : 1 / 4 / 9 / 16 / 5+1 / 7+1 views / custom : up to 10×10 views
• Synchronous playback : 16 channels

Intelligent video analytics

• Motion detection : Ajax camera : 16 channels / NVR : 16 channels
• AI object detection : Ajax camera : 16 channels

Interface

• HDD : 1 × SATA : supports hard drive with up to 16 TB capacity (3.5” form factor) ***HDD is not included
• Network : 1 × RJ-45 self-adaptive Ethernet (10/100 Mbps)
• USB : rear panel : 1 × USB 2.0 (Type-A) / side panel: 1 × USB 2.0 (Type-A) (To connect a keyboard, mouse, or a USB flash drive)

Network

• Bandwidth : incoming : up to 80 Mbps / outgoing : up to 40 Mbps
• Protocol : HTTP / HTTPS / TCP/IP / IPv4 / IPv6 / SNMP / RTSP / UDP / DHCP / DNS / DDNS
• Interoperability : ONVIF

Key features

• Supported devices : Ajax cameras / IP cameras using ONVIF (Profile S/T) or RTSP
• Built-in video management system : Integrated video wall interface with live camera feeds / Smart event filters for quick access to relevant footage / Interactive timeline with preview navigation for efficient playback and incident review
• Visual verification of Ajax system alarms
• Privacy

Power supply

• Main : 110–240 V / 50/60 Hz / 0.6 A
• Power consumption : up to 24 W
• Clock battery : CR2032 battery / 3 V

Enclosure

• Dimensions : 212 × 212 × 64 mm
• Weight : 782 g
• Operating temperature range : from 0 °C to +40 °C
• Operating humidity : up to 75%
• Protection class : IP20
