SJCAM Motorcycle Slot Bracket

The SJCAM Motorcycle Slot Bracket is a heavy-duty fixed mounting base designed to attach action cameras securely to a motorcycle's chassis, body frame, or fairing bolt slots. Built to deliver maximum stability during high-speed rides and off-road trips, it provides a low-profile anchor point for moto-vlogging, continuous road recording, or tracking shots.

• Sturdy Hybrid Build: Constructed from high-density ABS plastic and reinforced metal components for high resistance against wind force and engine vibration.
• Fixed Slot Base Mounting: Designed to fasten directly into motorcycle, scooter, or bike frame slots using existing bolt hardware.
• Low-Profile & Wind-Resistant: Sits flush against the motorcycle bodywork to minimize drag, turbulence, and footage shake at higher speeds.
• Universal Quick-Release Support: Interfaces with standard SJCAM quick-release buckles and pivoting extension arms.
• Compatibility: Compatible with all SJCAM models (C100, C200, C300, SJ4000, SJ8, SJ10, SJ11 series) and most standard 2-prong quick-release action camera mounting systems.

Specifications

Material Description

• Structure: A black metal L-shaped mounting arm with a single bolt hole at the bottom (for attaching under mirror mounts, fairing screws, or frame bolts).
• Top Plate: An anodized blue metal quick-release slot base held by four cross-head screws, designed to slide and clip into SJCAM quick-release buckle bases.

Included Parts (In the Box)

• 1× SJCAM Motorcycle Slot Bracket Base
• 1× Flat/Curved Adhesive Base Plate

Item Dimensions & Weight

• Bracket Base Dimensions: 6.5 cm × 4.2 cm × 3.0 cm
• Slot Channel Opening Width: 0.8 cm – 1.2 cm (Adjustable slot tolerance)
• Net Weight: 98 g
• Maximum Speed Rating: 160 km/h

Package Dimensions & Weight

• Package Length: 10.0 cm
• Package Width: 8.0 cm
• Package Height: 5.0 cm
• Gross Package Weight: 120 g
