Brateck TV Wall Bracket with Tilt for XL TVs up to 120” 900×600 Auto Lock/Release Max Weight 120kg LP73-69T

To address the gap in the niche market of heavy-duty large-sized TV wall mounts, the LP73-69T Affordable Heavy-Duty TV Wall Mount is a reasonable solution. A stiffener structure levels the weight capacity up to 120kg to firmly hold 60’’~120’’ TVs. Ample space in the center is perfect for installing the socket outlet and concealing all the messy cables. +10°~-10° toolless tilting mechanism provides the perfect viewing angle. A quick-release spring lock allows TV removal quick and easy and only takes seconds to install.

• Heavy-Duty Construction: provides extra strength and durability
• Toolless Tilt: allows for effortless positioning
• Reduced Package Size: relatively lower transport costs and storage fees (perfect for e-commerce platform sellers)
• Automatic Spring Locks with Quick Release Cords: allow TV removal quick and easy
• Open Architecture: provides increased ventilation and easier access to wires

Specifications

• Product Category: Tilt TV Wall Mount
• Rank: Standard
• Material: Steel
• Surface Finish: Powder Coating
• Color: Fine Texture Black
• Dimensions: 80 x 1005 x 602mm
• Fit Screen Size: 60"-120"
• Fit Curved TV: Yes
• Mounting Hole Pattern: VESA & Universal
• VESA Compatible: 50×50, 75×75, 100×100, 100×150, 150×100, 100×200, 200×100, 150×150, 200×200, 200×300, 300×200, 200×400, 400×200, 300×300, 300×400, 400×300, 600×200, 400×400, 600×300, 400×600, 600×400, 700×400, 800×400, 600×600, 800×500, 800×600, 900×600
• Max. Mounting Hole: 965x602mm
• Weight Capacity: 120kg
• Strength Tested: 4 Times Approved
• Profile: 80mm
• Tilt Range: +10°~-10°
• Screen Freely Tilting: Yes
• Installation: Solid Wall,Dual Stud(406mm/450mm/600mm)
• Panel Type: Detachable Panel
• Wall Plate Type: Fixed Wall Plate
• Direction Indicator: Yes
• Bubble Level: Hook-on Bubble Level(Included in Components Package)
• Accessory Kit Package: Normal/Ziplock Polybag,Compartment Polybag
• Certification: UL
