Brateck TV Mount ProAV 90×60 Turn 4-Arm 70cm 120kg LPA77-696

Heavy-duty arms provide strong support for larger and heavier TVs up to 120kg, LPA77-696 basically holds all types of TVs from 60” to 120”. TV installation and removal are made easy through a unique quick-release mechanism. Toolless tilting delivers optimal viewing angles. Integrated cable management creates a clean appearance.

• Free-Tilting Design: makes easy forward or backward adjustment for better viewing and reduced glare
• Cable Management: keeps everything organized
• Extending Arm: provides a wide range of viewing angles
• Quick-Release Latch: locks/unlocks the display in place
• Swiveling Arms: offer maximum viewing flexibility (makes every seat the best seat)

Specifications

• Product Category: Full-Motion TV Wall Mount
• Rank: Standard
• Material: Steel
• Pipe Size: 50 x 25 x 1.5mm Square Steel Tube
• Surface Finish: Powder Coating
• Color: Fine Texture Black
• Dimensions: 703 x 1010 x 630mm
• Fit Screen Size: 60"-120"
• Fit Curved TV: Yes
• Mounting Hole Pattern: VESA Only
• VESA Compatible: 200×200, 300×200, 400×200, 300×300, 400×300, 400×400, 600×400, 800×400, 800×600, 900×600
• Max. Mounting Hole: 910×610
• Weight Capacity: 120kg
• Strength Tested: 3 Times Approved
• Profile: 75~703mm
• Tilt Range: +5°~-15°
• Swivel Range: +60°~-60°
• Screen Level: +5°~-5°
• Screen Freely Tilting: Yes
• Installation: Solid Wall,Dual Stud(406mm/450mm/600mm)
• Panel Type: Detachable Panel
• Wall Plate Type: Fixed Wall Plate
• Direction Indicator: Yes
• Cable Management: Yes
• Bubble Level: Hook-on Bubble Level(Included in Components Package)
• Accessory Kit Package: Compartment Polybag
