HomeShopSecurityDoorphones & AccessZudsec Electric Bolt Lock ZDL-200T
Zudsec Electric Bolt Lock ZDL-200T

Zudsec Electric Bolt Lock ZDL-200T

€72.00

NC lock = Normally Closed No power →  unlocked Power ON →  locks NC = Needs power to stay closed Superier low temperature, Time delay design Lower power consumption, Enviromental protection Auto-reloc…

Delivery: 2-7 working days

Add to wishlist
SKU: MST-21164 Categories:Doorphones & Access, Electric Locks, Security Brand: Zudsec
  • Description
  • Additional information

NC lock = Normally Closed

No power →  unlocked

Power ON →  locks

NC = Needs power to stay closed

  • Superier low temperature, Time delay design
  • Lower power consumption, Enviromental protection
  • Auto-relock if no Action within 5 secs
  • Door status signal output contact (NC/NC/COM)
  • Safe & durable
  • Working Measure: power-on to lock
  • Suitable for: Wooden Door,Glass Door,Metal Door,Fire Proof Door
  • 2 Wire with Low Temperature & Time Delay
  • Input Voltage: DC12V
  • Working Current: 900mA; Static Current: 100mA
  • Working Measure: Fail safe, Locked when powered oon.
  • Fail-safe type:: Power to lock
  • Coil type: Continuous working
  • Solid Bolt: polishing housing, 800Kg Holding Force
  • Surface Temp: Low Temperature
  • Induction Distance:8mm
  • Dimension: Face Plate: 205Lx35WX40H(mm) / Strike: 90Lx25Wx2H(mm) / Bolt diameter: 16mm;  Bolt length: 16mm
  • Operating temp: -10~+25℃(14-131F)
  • Operating Humidity: 0~90%
  • Special Designed: Tested to 500000 cycles
  • Face place material:High Aluminum, Carrulous Line Finished

Additional information

Brand

Zudsec

Lock Type

Electric Bolt

Product Type

Lock

MPN

ZDL-200T
