HomeShopNetworkingCables & ConnectorsDahua CAT5e CPR OFC FTP Cable 305m 0.52mm Gray PFM920I-5EF
Dahua CAT5e CPR OFC FTP Cable 305m 0.52mm Gray PFM920I-5EF

Dahua CAT5e CPR OFC FTP Cable 305m 0.52mm Gray PFM920I-5EF

€187.00

305.0 m (1000 ft)/carton FTP CAT5E, power over Ethernet, compatible with one cable High-purity Oxygen-Free Copper conductor material Customized PVC outer sheath; meet CE CPR Eca and ANSI/TIA 568-C.2 flame retardant class…

Delivery: 2-7 working days

Add to wishlist
SKU: MST-28455 Categories:Cables & Connectors, LAN Cable, Networking Brand: Dahua
  • Description
  • Additional information
  • 305.0 m (1000 ft)/carton FTP CAT5E, power over Ethernet, compatible with one cable
  • High-purity Oxygen-Free Copper conductor material
  • Customized PVC outer sheath; meet CE CPR Eca and ANSI/TIA 568-C.2 flame retardant class certified
  • 10-year warranty

Specifications

Conductor

  • Material : Oxygen free copper (99.95% purity)
  • Diameter : 0.52 mm ± 0.02 mm (0.0204" ± 0.0007")
  • Wire Gauge : 24 AWG

Insulation

  • Material : HDPE
  • Min. Average Thickness : 0.25 mm (0.0098")
  • Diameter : 1.04 mm ± 0.05 mm (0.0409" ± 0.0019")
  • Color : 4 pairs, Blue, white/blue; orange, white/orange; green, white/green; brown, white/brown

Rip Cord

  • Material : Polyester
  • Specification : 500D

Drain Wire

  • Material : Solid tinned copper
  • Specification : 0.50 mm ± 0.10 mm (0.0196" ± 0.0039")

Shielding

  • Material : Polyester aluminum foil
  • Specification : 19 × 0.065 mm (19 × 0.0025")

Sheath

  • Material : PVC
  • Min. Average Thickness : 0.40 mm (0.0157")
  • Diameter : 6.2 mm ± 0.5 mm (0.2440" ± 0.0196")
  • Color : Gray

Electrical

  • Max. DC Resistance of a Single Conductor (20°C) : 9.5 Ω / 100 m
  • Insulation Resistance : 5000 MΩ·km
  • Max. DC Resistance Unbalance : 2% (pair intra), 4% (pairs inter)
  • Unbalanced Line-to-Ground Capacitance : 160 pF / 100 m
  • Working Capacitance : 56 pF / 100 m

Transmission

  • Characteristic Impedance : 100 Ω ± 15 Ω
  • Near End Cross Talk : ≥35.30 dB / 100 m @ 100 MHz
  • Max. Attenuation : ≤22.0 dB / 100 m @ 100 MHz
  • Return Loss : ≥20.1 dB / 100 m @ 100 MHz

Mechanical

  • Tensile Strength : Sheath ≥13.5 MPa, insulation ≥16 MPa
  • Elongation at Break : Sheath ≥150%, insulation ≥300%
  • Installation Bending Radius : >8 times of outer cable diameter

Environmental

  • Color Migration Resistance of Insulation : No migration
  • Low Temperature Bending Test : No cracking after the test
  • Heat Shock Test : No cracking after the test
  • Operating Temperature : –20 °C to +75 °C (–4 °F to 167 °F)
  • Installation Temperature : 0 °C to +60 °C (32 °F to 140 °F)
  • Storage Temperature : –15 °C to +75 °C (5 °F to 167 °F)

Packaging

  • Cable Length : 305.0 m ± 2.0 m (1,000.66 ft ± 6.56 ft)
  • Packaging Dimensions : 350 mm × 350 mm × 300 mm (13.77" × 13.77" × 11.81") (L × W × H)
  • Packaging Method : 305.0 m (1,000.66 ft) a roll, plywood wooden shaft
  • Net Weight : 11.5 kg ± 0.5 kg (25.35 lb ± 1.10 lb)
  • Gross Weight : 14.0 kg ± 0.5 kg (30.86 lb ± 1.10 lb)

Compliance

  • Executive Standards : ANSI/TIA 568-C.2
  • Certifications : CPR Eca

Additional information

Brand

Dahua

Type

Cat5e

Cable Type

FTP

Conductor

Pure Copper

Environment

Indoor

Length

305m

Colour

Grey

MPN

DH-PFM920I-5EF-gray
